OPERATION INTERFACE

With our software,you can easily program and control the robot on platform.Expand the functionality of HK5404 by integrating with vision.


WORK SPACE

  • Side View

  • Top View

SPECIFICATIONS

Working radius540mm
Number of axis3/4
InstallationFloor
N.W.13kg
Position repeatability士0.05mm
Max payload1kg
Power supplyInput: single phase 110V-240V 50Hz Output: DC 24V(400W)
External communicationWIFI/Ethernet
Safety standardISO 9001-2015
Control softwareHULK STUDIO
Drive systemsteper motor
I/OInput 5/Output 5
Working condition-10°C~60°C
applicationpicking, loading, casting, polishing Etc
Max Speed Of Axis 1360°/s
Max Speed Of Axis 2360°/s
Max Speed Of Axis 3360°/s
Max Speed Of Axis 4500°/s
Workspace of Axis 1士160°
Workspace of Axis 2-42°~85
Workspace of Axis 3-20°~100°
Workspace of Axis 4士160°

Control Box


CLAWS DESIGN

Hulk robot products can be adapted to different specifications of end-effector, and support expansion for third-party. The strong compatibility of Hulk robots ensures that it is flexible and convenient. It can be quickly replaced the terminal according to the needs of use, and efficiently complete a variety of tasks.

  • Strong compatibility

  • Flexible and convenient

  • Easy programming

    • Sucker

    • Mechanical Gripper

    • Adaptive Gripper

    • Electric Screw

    • ELectric magnetic Gripper

    • Soft Gripper

    • Electric gripper

    • Hot Air Gun

    Package
